IPL SHR Diode Laser 2 in 1 Hair Removal Device
Advanced SHR Diode Laser Multifunctional beauty machine covers over 7 functions. It is professional beauty salon hair removal equipment.
Machine Model: ADPL2D-AH
Beauty System Type: SHR Diode Laser Multifunction Beauty Machine
- System 1: Diode Laser (permanent laser hair removal)
- System 2: IPL SHR OPT (acne therapy, photorejuvenation, skin whitening, hair removal)
Suitable For: Professional beauty salons, clinics, medical centers
Certificates: FDA, Medical CE, CE, RoHS, ISO 13485
SHR Diode Laser Handles Details
Diode Laser System AH
Diode Laser is best in permanent laser hair removal. It provides permanent effect and truly painless treatment.
Diode laser handle adopts US Coherent laser bars (which is the same brand with German Dilas, the best brand for diode laser stacks) and can ensure 20 million shots lifespan at least 4-5 years normal using!
This diode laser handle equipped with unique double cooling systems, treatment tip Sapphire skin contacting cooling plus the extra cooling tip for pre and post cooling for the hair removal area, ensure truly painless and permanent hair removal effect!
Amazing Cooling effect of Diode Laser
CIA™ Technology- Cooling In Advance
We uses 25mm * 25mm TEC cooling tips to cool the skin before, during and after treatments. It can protect the epidemis from hurt, reduce the pain during hair removal, and increase the comfort for patients.
ICE™ Technology – Simultaneous contact cooling
It is an advanced technology that cools the skin continuously during treatments. It minimizes the risk of burns on the epidermis while maintaining heat to penetrate dermis where hair follicles are.
IPL SHR OPT System
Our IPL SHR system will come with 5 changeable filters with different functions:
- 480nm: Acne treatment
- 530nm: Vascular treatment, photofacial for light skin.
- 590nm: Pigmentation treatment, photofacial for dark skin.
- 640nm: Hair reduction for light skin
- 690nm: Hair reduction for dark skin
Super 1 Million Shot Lifespan for IPL SHR OPT
Unbelievable lifespan of 1,000,000 shots, at least 5 times longer than others!
Why other’s IPL SHR OPT System only has 300,000 shots lifespan while our machine can reach amazing 1 million shots lifespan?
As we all know, the laser bar in diode laser has very high demand for water quality, so in every diode laser machine there will be water filter.
But since xenon lamp doesn’t have that high demand for water, so no factory will apply water filter in IPL SHR series machines.
But we applied, we applied an EXTRA water filters to protect our UK imported xenon lamp.
Water filter is to filter out the impurities from water. This can greatly prolong the lifespan the lamp to 1 million shots.
Specification of IPL SHR Diode Laser 2 in 1 Multifunctional Beauty Machine
| Specifications | Diode laser | SHR OPT IPL |
|---|---|---|
| Lifespan | 20 million shots | 1 million shots |
| Power | 500W for laser, 2000W for power | 2000W |
| Spot Size | 15*15mm | 15*50mm OR 12*30mm |
| Wavelength | 808nm / Triple (75 5+808+1064) | 480nm 530nm 590nm 640nm 690nm |
| Energy Density | 1-166J/cm2 | 50J/cm2 |
| Pulse Frequency | 1-10Hz | 1-10Hz |
| Laser Bars/ Lamp | US Coherent laser bars | UK Xenon lamp |
| Cooling Level | Sapphire Crystal + Air + Closed Water Circulation + Semiconductor +TEC | |
| Display | 10.4 inch True Color LCD touchable Screen | |
| Stand-by Working | Continuous stand-by working for 10-12hours | |
| Electrical | 100/110V, 50~60Hz, /230V~260V,50~60Hz | |
| Gross Weight | 47 KG | |
| Packing Dimension | 61*65*49cm (W*D*H) | |
Diode IPL Beauty Equipment Before & After
Chin diode laser hair removal
SHR leg hair removal
IPL photofacial
IPL acne therapy
IPL pigmentation therapy
High Quality Inner Spare Parts We Use in Diode Laser + IPL Beauty Machine
- 2000W power supply for diode laser system, 2000W power supply for IPL SHR OPT system
- Korea imported water filter, to filter out the impurities and ions from water, so that can protect our US Coherent laser bars and UK imported xenon lamp very well, thus can greatly prolong the lifepsan of machine.
- Thickest aluminum radiators plus 2 big fans to ensure the excellent heat dissipation effect. Heat dissipation system is very important for the lifespan and quality of the machine.
- Why we use alum radiator instead of cooper radiator: It is because copper rusting, the rust is very harmful to laser bars and xenon lamp.
The heat conductivity of copper is 1/3 better than alum if the room temperature is low, but if the room temperature is high, there will not big difference on heat conductive between copper and alum. Besides, our water tank is 6L for portable and 8L for vertical, it is big enough to support a good heat dissipation system, so after analysis, we finally choose alum radiator
- 2*22000uf big capacitors imported from Japan for IPL SHR system. (Even it is a portable 2 handpieces machine, we still use 44000 uf for IPL, instead of 30000 uf.)
- 6L acrylic water tank
- Latest brushless DC water pump, with lift 15m. Compare with the outdated magnetic drive pump, the brushless DC pump we use has much lower noise and much higher water flow speed. High water flow speed means it can take away the heat very quickly and protect the machine.
- Schneider switches
Most importantly, we use independent power supply for each system, this can ensure each system has strong and stable energy!
Easy Interface for IPL SHR Diode Laser 2 in 1 Machine
This IPL SHR Diode Laser 2 in 1 beauty equipment is very easy to operate with below features:
- Intelligent operating system
- Pre-set parameters Treatment records saving
- 15 Languages available
- Monitoring system
- Alarming system
- Renting mode
- Saving client treatment data
The software is designed by our engineer with preset therapy parameters and even starters can use it so easily!
Record Saving System
We also have this really useful client treatment record saving system.
Every patient has different skin tone and hair type. Even patients who have similar skin and hair type, they may have different tolerence about pain.
So when doing treatment to a new client, Doctor usually has to try from low energy in patient skin and gradually higher, find the most suitable parameter for this specific patient.
Our system allows Doctor to save this most suitable parameter for this specific patient to our Treatment Record Saving System. So that next time when this patient come again, Doctor can directly searching for his or her well tested parameters and start treatment quickly.
Special design, easy to change water filter
Our new design has put water filter out of machine shell. It is very convenient to observe water filter status.
If water filter turns dirty or machine alarming system indicates water filter need to be changed, client can easily change water filter from back of the machine.
No need to open machine shell, even salon technicians can do it very quick and easily!
“This is the ever best model I have purchased from China. It is effective, safe and all my patients are so happy with the effect! I recommend this supplier to anyone who need such lasers!”
“Before I buy this 2 in 1 laser, I don’t believe a multifunctional system can have such good effect and quality. Diode laser system is superb and IPL system is working best in my photofacial therapies! I love this machine and will definitely buy more machines from TEC DIODE!”
“Happy with the effect and supplier’s service, recommended!”
Stelle Laser is an innovate aesthetic & beauty machine manufacturer in China. We produce and sell Diode laser hair removal machine, IPL photorejuvenation machine, ND Yag Laser tattoo removal and pigment treatment machine, Carbon Peel machine, CO2 Fractional Laser and Multifunctional beauty machines combining above handles.
